Raleigh Route IE Specs and reviews
Raleigh Route IE specs
| General Information | |
|---|---|
| Model Name | Raleigh Route IE |
| Brand/Manufacturer | Raleigh |
| Year of Release | 2021 |
| Country of Origin | United States |
| Electric Bike Type | commuter |
| Intended Use | urban commuting |
| Frame & Geometry | |
| Frame Material | aluminum |
| Frame Style | diamond |
| Frame Size Options | S, M, L, XL |
| Axle Type and Standard | 12x142mm |
| Bottom Bracket Type | standard |
| Internal Cable Routing | true |
| Motor & Electrical System | |
| Motor Brand and Model | Bosch Performance Line |
| Motor Type | mid-drive |
| Motor Power | 250 watts |
| Torque | 65 Nm |
| Pedal Assist Levels | 4 |
| Battery Capacity | 500 Wh |
| Battery Brand and Position | integrated |
| Estimated Range | up to 100 km |
| Charging Time | 4-6 hours |
| Display Type and Features | LCD |
| App Connectivity or Integration | false |
| Drivetrain | |
| Drivetrain Type | 1x |
| Number of Speeds | 9 |
| Derailleur Model | Shimano Deore |
| Shifter Brand and Model | Shimano |
| Crankset Details | 170mm / 42T |
| Cassette Range | 11-36T |
| Chain or Belt Drive System | chain |
| Braking System | |
| Brake Type | hydraulic disc |
| Brake Brand and Model | Shimano MT200 |
| Rotor Size | front: 180mm / rear: 160mm |
| Brake Mount Standard | post mount |
| Wheels & Tires | |
| Wheel Size | 700c |
| Rim Type and Width | double-wall alloy |
| Hub Type | geared hub |
| Tire Brand, Model, Width | Schwalbe Big Ben, 35mm |
| Tire Type | puncture-resistant |
| Max Tire Pressure | 65 psi |
| Cockpit & Contact Points | |
| Handlebar Type and Width | flat, 680mm |
| Handlebar Material | aluminum |
| Stem Length and Angle | 90mm, 7-degree |
| Saddle Brand and Model | Raleigh comfort saddle |
| Seatpost Type | rigid |
| Pedals Included | yes, platform |
| Accessories & Features | |
| Lights | integrated front and rear |
| Fenders and Racks | fenders included |
| Kickstand Type | center mount |
| Bell or Horn | bell included |
| GPS or Anti-Theft Features | none |
| Safety & Compliance | |
| Certifications | EN 15194 |
| Water/Dust Resistance | IP54 |
| Performance & Ride Quality | |
| Claimed Weight | approximately 20 kg |
| Max Assisted Speed | 25 km/h |
| Ride Quality Highlights | comfort / stability |
| Packaging & Delivery | |
| Assembly Required | 90% complete |
| Box Dimensions | 140 x 80 x 20 cm |
| Shipping Weight | 25 kg |
| Price & Availability | |
| MSRP | $2,499 |
| Market Availability | United States, Canada, Europe |
| Warranty | frame: 5 years, battery: 2 years, motor: 2 years, electronics: 2 years |
| Color Options | black, silver |
Pros and Cons of Raleigh Route IE
| Pros | Cons |
|---|---|
| Lightweight aluminum frame | May be less durable compared to steel frames |
| Shimano gears for smooth shifting | Higher cost compared to entry-level bikes |
| Comfortable saddle for long rides | May not have as many customization options |
| Responsive disc brakes for reliable stopping power | Requires more maintenance compared to rim brakes |
Common Issues and Problems with Raleigh Route IE
| Common Problems Associated with Raleigh Route IE Bike: |
| 1. Battery not holding a charge for the expected duration |
| 2. Motor making unusual noises during operation |
| 3. Brakes squeaking or not providing sufficient stopping power |
| 4. Display screen malfunctioning or displaying incorrect information |
| 5. Gears shifting erratically or slipping under load |
| 6. Tire punctures occurring frequently despite proper inflation |
| 7. Frame developing cracks or structural weaknesses over time |
| 8. Electrical system failure leading to loss of pedal assistance |
User Reviews of Raleigh Route IE
| Name | Review |
|---|---|
| Emily | The Raleigh Route IE bike is a fantastic electric bike. The battery life is impressive, and it makes my daily commute much more enjoyable. |
| Mike | I've had the Raleigh Route IE for a few months now, and it has exceeded my expectations. The pedal-assist feature is great for longer rides. |
| Sarah | As a beginner cyclist, I found the Raleigh Route IE to be easy to use and comfortable. It has helped me build my confidence on the road. |
| David | The Raleigh Route IE is a well-built bike with a sleek design. I appreciate the attention to detail in its construction. |
Common Questions About Raleigh Route IE
-
What is the estimated range of the Raleigh Route IE?
The estimated range of the Raleigh Route IE is up to 100 km on a single charge.
-
Does the Raleigh Route IE come with integrated lights?
Yes, the Raleigh Route IE comes with integrated front and rear lights for enhanced visibility.
-
What type of brakes does the Raleigh Route IE have?
The Raleigh Route IE features hydraulic disc brakes with Shimano MT200 as the brake brand and model.
-
Are fenders included with the Raleigh Route IE?
Yes, fenders are included with the Raleigh Route IE for protection against splashes and debris.
-
How long does it take to charge the battery of the Raleigh Route IE?
The battery of the Raleigh Route IE takes approximately 4-6 hours to fully charge.
-
What is the maximum tire pressure recommended for the Raleigh Route IE?
The recommended maximum tire pressure for the Raleigh Route IE is 65 psi.
-
Does the Raleigh Route IE offer any anti-theft features?
No, the Raleigh Route IE does not have GPS or anti-theft features integrated.
-
What are the color options available for the Raleigh Route IE?
The Raleigh Route IE is available in black and silver color options.
-
What type of drivetrain does the Raleigh Route IE have?
The Raleigh Route IE features a 1x drivetrain with 9 speeds and a Shimano Deore derailleur.
-
Is app connectivity or integration available on the Raleigh Route IE?
No, the Raleigh Route IE does not offer app connectivity or integration features.
